| Model | YZ-4es | |
| Dispensing Bottles | 4 | |
| Precooled Bottles | 20 | |
| Dispensing Type | quantificationally dispensing by glass | |
| Wine Output Level（mL/glass) | 5-750ml per preset | |
| Wine Switch Type | touching screen | |
| Wine Output Level Shift Switch | touching screen | |
| Display of Wine Qty. in Bottle | YES | |
| Alarm of Wine/Gas Use-up | YES | |
| Cooling Method | state-of-the-art thermoelectric | |
| Control Temperature (℃) | 12~18 | |
| Power Supply | 220~240V/50Hz/1PH, 110-120V/60HZ/1PH | |
| Total Power (W) | 120 | |
| Power Consumption (kW·h/24h) | 1.3 | |
| Net Dimensions（W×D×H，mm） | 460×602×900 | |
| Gross Dimensions（W×D×H，mm） | 540×682×960 | |
| Net Weight（kg） | 30 | |
| Gross Weight（kg） | 35 | |
| Std. Gas Source | ≥99.999% high purity argon | |
| Outside Material | SUS304, steel, PMMA, coated glass | |
| Std. Accessories | wine tube cleaner (1pcs), pressure reducing valve assembly (1 set) |
|
| Stds. Implemented | GB 4706.1-2005 GB 4806.1-1994 GB/T 23777-2009 GB/T 4842-2006 NSF/ANSI 51-2012 FDA 21 CFR 177.2470 FDA 21 CFR 177.2510 FDA 21 CFR 177.1210 FDA 21 CFR 177.1680 |
|
| Certificates/Tests | CE, FDA, Keeping bottle-opened wines fresh 20-days authoritative test | |
| FCL (pcs) | 20GP | 62 |
| 40GP | 132 | |
| 40HQ | 132 |
