Values Features Specifications Downloads



 *Ultimate Experience Adjustable wine output per glass of 5 level precise quantificationally dispensing by glass plus 1 level manually dispensing per demand + Real time display of remaining wine in bottle + Display of wine output per glass + Alarm of wine use up or insufficient .

*Ultimate Hygiene Unique in the industry that no wine residual but inert gas seal inside both wine outlet and whole wine tubing after dispensing wine.

*Ultimate Safety Remote control lock for wine dispensing module + All materials directly or possibly touching wine get NSF51 or FDA approved + CE certificated.

*Ultimate Fresh-keeping Keep bottle-opened wine fresh 20 days as 3rd party authoritative organization tested.

*Ultimate Gas-source≥99.999% high purity argon to push wine out and avoid oxygen going into wines.

*Ultimate Applicability Creative bottle resealing plug suited for all-size bottle height and bottlenecks.

*Ultimate Bottle-connectionUnique in the industry that one step "direct push-in" bottle connection to eliminate gas leakage at bottleneck caused by misoperation .

*Ultimate Cleaning Two-times easiest cleaning to thoroughly clean whole wine tubing without disassembling any components.

*Ultimate Gas-tightness Top quality pneumatic fittings to ensure perfect gas tightness and lowest use-cost so that one 5L gas cylinder could support 500 bottles 750mL wine dispensing.







Model   YZ-2es
Dispensing Bottles   2
Precooled Bottles   8
Dispensing Type   quantificationally dispensing by glass
Wine Output Level(mL/glass)   5-750ml per preset
Wine Switch Type   touching screen
Wine Output Level Shift Switch   touching screen
Display of Wine Qty. in Bottle   YES
Alarm of Wine/Gas Use-up   YES
Cooling Method   state-of-the-art thermoelectric
Control Temperature (℃)   8~18
Power Supply   220~240V/50Hz/1PH, 110-120V/60HZ/1PH
Total Power (W)   71
Power Consumption (kW·h/24h)   0.7
Net Dimensions(W×D×H,mm)   252×570×765
Gross Dimensions(W×D×H,mm)   332×650×825
Net Weight(kg)   18
Gross Weight(kg)   21
Std. Gas Source   ≥99.999% high purity argon
Outside Material   SUS304, steel, PMMA, coated glass
Std. Accessories   wine tube cleaner (1pcs),
pressure reducing valve assembly (1 set)
Stds. Implemented   GB 4706.1-2005
GB 4806.1-1994
GB/T 23777-2009
GB/T 4842-2006
NSF/ANSI 51-2012
FDA 21 CFR 177.2470
FDA 21 CFR 177.2510

FDA 21 CFR 177.1210
FDA 21 CFR 177.1680
Certificates/Tests   CE, FDA, Keeping bottle-opened wines fresh 20-days authoritative test
FCL (pcs) 20GP 126
40GP 252
40HQ 376
